M2303ADN Datasheet - MPS

Synchronous Rectified Step-Down Converter

M2303ADN Features

* 3A Output Current

* Wide 4.7V to 28V Operating Input Range

* Integrated MOSFET Switches

* Output Adjustable from 0.80V to 25V

* Up to 95% Efficiency

* Programmable Soft-Start

* Stable with Low ESR Ceramic Output Capacitors

* Fixed 360kHz Frequency

* Cycle-by-Cyc

M2303ADN General Description

The MP2303A is a monolithic synchronous buck regulator. The device integrates a 150mΩ O high-side MOSFET and a 80mΩ low-side F MOSFET that provide 3A continuous load current over a wide operating input voltage of 4.7V to 28V. Current mode control provides fast D transient response and cycle-by-cycle.

M2303ADN Datasheet (814.23 KB)

M2303ADN Datasheet Preview — Preview of M2303ADN PDF

Datasheet Details

Part number:

M2303ADN

Manufacturer:

MPS

File Size:

814.23 KB

Description:

Synchronous rectified step-down converter.
