MP2482 - 420kHz Step-Down Converter

MPS

The MP2482 by MPS is a 420kHz Step-Down Converter. Below is the official datasheet preview.

📥 Download Datasheet

MP2482 420kHz Step-Down Converter by MPS - Datasheet Preview — Official preview page of the MP2482 420kHz Step-Down Converter datasheet (MPS).

Datasheet Details

Part number	MP2482
Manufacturer	MPS
File Size	382.68 KB
Description	420kHz Step-Down Converter
Datasheet	MP2482-MPS.pdf
Additional preview pages of the MP2482 datasheet.

MP2482 Product details

Description

The MP2482 is a monolithic step-down switch mode converter with a built in internal power MOSFET.

Features

Wide 4.5V to 30V Operating Input Range.
5A Output Current.
50mΩ Internal Power MOSFET Switch.
Power Good Indicator.
Fixed 420kHz Frequency.
Synchronizable up to 1.5MHz.
Cycle-by-Cycle Over Current Protection with hiccup.
Thermal Shutdown.
Output Adjustable from 0.81V.
Stable with Low ESR Output Ceramic Capacitors.
Available in 8-Pin SOIC Package and Thermally Enhanced 8-Pin SOIC Package.
