MP2482DN

420kHz Step-Down Converter

MP2482DN Features

* Wide 4.5V to 30V Operating Input Range

* 5A Output Current

* 50mΩ Internal Power MOSFET Switch

* Power Good Indicator

* Fixed 420kHz Frequency

* Synchronizable up to 1.5MHz

* Cycle-by-Cycle Over Current Protection with hiccup

* Therma

MP2482DN General Description

The MP2482 is a monolithic step-down switch mode converter with a built in internal power MOSFET. It achieves 5A continuous output current over a wide input supply range with excellent load and line regulation. Current mode operation provides fast transient response and eases loop stabilization. Fau.

MP2482DN Datasheet (382.68 KB)

Preview of MP2482DN PDF

Datasheet Details

Part number:

MP2482DN

Manufacturer:

MPS

File Size:

382.68 KB

Description:

420khz step-down converter.
