MP8736 High Efficiency 6A 19V Synchronous Buck Converter

MP8736 Description

The Future of Analog IC Technology MP8736 High Efficiency, Fast Transient, 6A, 19V Synchronous Buck Converter in a Tiny QFN20 (3x4mm) Package DESCRI.
The MP8736 is a fully integrated high frequency synchronous rectified step-down switch mode converter.

MP8736 Features

* include SCP, OCP, OVP, UVP and thermal shut down. The MP8736 requires a minimum number of readily available standard external components and is available in a space saving QFN20 (3x4mm) package. FEATURES
* Wide 4.5V to 19V Operating Input Range
* 6A Output Current
* Integrated 30mΩ High

MP8736 Applications

* Networking Systems
* Broadband/Optical Communication Systems
* Distributed Power and Point of Load Systems All MPS parts are lead-free and adhere to the RoHS directive. For MPS green status, please visit MPS website under Quality Assurance. “MPS” and “The Future of Analog IC Technolog

📥 Download Datasheet

Preview of MP8736 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
MP8736
Manufacturer
MPS
File Size
1.40 MB
Datasheet
MP8736-MPS.pdf
Description
High Efficiency 6A 19V Synchronous Buck Converter
