MPM3686GRU 18V 20A Step-Down Power Module

The MPM3686 is an easy-to-use fully integrated 20A step-down DC/DC power module. It integrates the DC/DC converter, power inductor, input/output capacitors and the necessary resistors/capacitors in a compact QFN 12mmX15mmX4mm package. This total power solution needs as few as two external components.

MPM3686GRU Features

* that include over-current protection, over-voltage protection and thermal shutdown. FEATURES

* Complete 20A DC-to-DC Solution

* Wide Input Voltage Range from 2.5V:

* 2.5V to 18V with External 5V Bias

* 4.5V to 18V with Internal Bias

* 1% Reference Voltage Ove

MPM3686-MPS.pdf

MPM3686GRU Datasheet Preview — This datasheet PDF includes multiple part numbers: MPM3686GRU, MPM3686. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

MPM3686GRU, MPM3686

Manufacturer:

MPS

File Size:

1.02 MB

Description:

18v 20a step-down power module.

Note:

This datasheet PDF includes multiple part numbers: MPM3686GRU, MPM3686.
Please refer to the document for exact specifications by model.
