MAP3232 Datasheet, Driver, MagnaChip

MAP3232 Features

• Driver Dual output into single package Wide input voltage range : 8.5V ~ 36V Dual PWM and Analog Dimming Current Mode Control Type Adjustable SW frequency : 100kHz ~ 500kHz 10V Gate Drive Refe

PDF File Details

Part number:

MAP3232

Manufacturer:

MagnaChip

File Size:

604.39kb

Download:

📄 Datasheet

Description:

Dual channel switch mode operating led driver. MAP3232 is high efficiency dual channel boost type PWM driver in single package. It is designed for high brightness LED driver optimi
