DS1088E - Fixed-Frequency EconOscillator

Description

The DS1088E is a low-cost clock generator that produces a square-wave output without external timing components.

The fixed-frequency oscillator is available in a factory-calibrated frequency of 133MHz.

The device has a power-down pin for power-sensitive applications.

Optical Modu

Features

  • Factory-Programmed, 133MHz Square-Wave Generator.
  • Single Output.
  • No External Timing Components Required.
  • 2.85V to 3.6V Supply.
  • Power-Down Mode.
  • Wide Temperature Range (-40°C to +95°C) EconOscillator is a trademark of Maxim Integrated Products, Inc. Ordering Information appears at end of data sheet. For related parts and recommended products to use with this part, refer to www. maximintegrated. com/DS1088E. related. Typical Operating Circuit 133MHz OUTPUT VCC.
