MAX17024 - Single Quick-PWM Step-Down Controller

Product Overview

Maxim Integrated

Datasheet Details

Part number	MAX17024
Manufacturer	Maxim Integrated
File Size	682.02 KB
Description	Single Quick-PWM Step-Down Controller
Datasheet	MAX17024 Datasheet
Additional preview pages of the MAX17024 datasheet.

Product details

Description

The MAX17024 pulse-width modulation (PWM) controller provides high efficiency, excellent transient response, and high DC-output accuracy needed for stepping down high-voltage batteries to generate lowvoltage core or chipset/RAM bias supplies in notebook computers.

Features

o Quick-PWM with Fast Transient Response o Supports Any Output Capacitor No Compensation Required with Polymers/Tantalum Stable with Ceramic Output Capacitors Using External Compensation o Precision 2V ±10mV Reference o Dynamically Adjustable Output Voltage (0 to 0.9 x VIN Range) Feedback Input Regulates to 0 to 2V REFIN Voltage 0.5% VOUT Accuracy Over Line and Load o 26V Maximum Input Voltage Rating o Resistively Programmable Switching Frequency o Undervoltage/Thermal Protection o Voltage Soft-.
