MAX1968 - Power Drivers for Peltier TEC Modules

Description

The MAX1968/MAX1969 are highly integrated and costeffective, high-efficiency, switch-mode drivers for Peltier thermoelectric cooler (TEC) modules.

Both devices utilize direct current control to eliminate current surges in the TEC.

Features

  • High Accuracy and Adjustability Improves System Performance by Optimizing TEC Operation.
  • Direct Current Control Prevents TEC Current Surges.
  • Ripple Cancellation for Low Noise.
  • No Dead-Zone or Hunting at Low-Output Current.
  • 1% Accurate Voltage Reference.
  • Adjustable TEC Voltage Limit.
  • Separately Adjustable Heating and Cooling Current Limits.
  • ITEC Output Provides Proportional Voltage to TEC Current for Monitoring.
