TH7110 - FSK/FM/ASK Receiver

Product Overview

Melexis

Datasheet Details

Part number	TH7110
Manufacturer	Melexis
File Size	699.18 KB
Description	FSK/FM/ASK Receiver
Datasheet	TH7110 Datasheet
Additional preview pages of the TH7110 datasheet.

Product details

Description

The TH7110 receiver IC consists of the following building blocks: " PLL synthesizer (PLL SYNTH) for generation of the first and second local oscillator signals LO1 and LO2 " Parts of the PLL SYNTH are the high-frequency VCO1, the feedback dividers DIV_8 and DIV_2, a phase-frequency detector (PFD) with charge pump (CP) and a crystal-based reference oscillator (RO) " Low-noise amplifier (LNA) for high-sensitivity RF signal reception " First mixer (MIX1) for down-conversion of the RF signal to the

Features

! Double superhet architecture for high degree of image rejection ! FSK for digital data and FM reception for analog signal transmission ! FM/FSK demodulation either with phase-coincidence or PLL demodulator ! Low current consumption in active mode and very low standby current ! Switchable LNA gain for improved dynamic range ! AFC feature allows wide carrier frequency acceptance range ! RSSI allows signal strength indication and ASK detection ! Surface mount package LQFP44 Ordering Information.
