PIC16F767, PIC16F7x7 Datasheet - Microchip Technology

PIC16F767 8-Bit CMOS Flash Microcontroller

PIC16F767 Features

* Power-Managed modes: - Primary Run (XT, RC oscillator, 76 A, 1 MHz, 2V) - RC_RUN (7 A, 31.25 kHz, 2V) - SEC_RUN (9 A, 32 kHz, 2V) - Sleep (0.1 A, 2V)

* Timer1 Oscillator (1.8 A, 32 kHz, 2V)

* Watchdog Timer (0.7 A, 2V)

* Two-Speed Oscillator Start-up Oscillat

PIC16F7x7_Microchip.pdf

PIC16F767 Datasheet Preview — This datasheet PDF includes multiple part numbers: PIC16F767, PIC16F7x7. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

PIC16F767, PIC16F7x7

Manufacturer:

Microchip ↗ Technology

File Size:

5.04 MB

Description:

8-bit cmos flash microcontroller.

Note:

This datasheet PDF includes multiple part numbers: PIC16F767, PIC16F7x7.
Please refer to the document for exact specifications by model.
