Description

TheTC500/A/510/514 family are precision analog front ends that implement dual slope A/D converters having a maximum resolution of 17 bits plus sign.

Features

Precision (up to 17 bits) A/D Converter “Front End”.
3-Pin Control Interface to Microprocessor.
Flexible: User Can Trade-off Conversion Speed for Resolution.
Single-Supply Operation (TC510/TC514).
4 Input, Differential Analog MUX (TC514).
Automatic Input Voltage Polarity Detection.
Low Power Dissipation: - (TC500/TC500A): 10 mW - (TC510/TC514): 18 mW.
Wide Analog Input Range: - ±4.2V (TC500A/TC510).
Directly Accep.
