1N3023B-1

(1N3016B-1 - 1N3045B-1) 1 Watt Glass Case Zener Diodes

1N3023B-1 Features

* JEDEC registered 1N3016 through 1N3045 numbers. Zener voltage range: 6.8 volts to 110 volts. Hermetically sealed DO-41 glass package. Metallurgically bonded. Double plug construction. Voltage tolerances of 5%, 2%, and 1%

1N3023B-1 General Description

This well established Zener diode series for the 1N3016B-1 through 1N3045B-1 JEDEC registration in the glass DO-41 package provides a glass hermetic seal for 6.8 to 110 volts. It is also well suited for high-reliability applications where it is available in JAN, JANTX, and JANTXV military qualifica.

1N3023B-1 Datasheet (359.71 KB)

Preview of 1N3023B-1 PDF

Datasheet Details

Part number:

1N3023B-1

Manufacturer:

Microsemi ↗

File Size:

359.71 KB

Description:

(1n3016b-1 - 1n3045b-1) 1 watt glass case zener diodes.
1N3016B-1

* 1N3045B-1 Qualified Levels: JAN, JANTX, and JANTXV Available on commercial versions 1 Watt Glass Case Zener Diodes Qualified per.
