1N5750B

Axial-Leaded 500 mW Zener Diodes

Microsemi

1N5750B Features

* JEDEC registered 1N5728 to 1N5757 series

* Internal metallurgical bond option available by adding a “-1” suffix

* Options for screening in accordance with MILPRF-19500 for JAN, JANTX, JANTXV, and JANS are available by adding MQ, MX, MV, or MSP prefixes respectively to part

1N5750B General Description

The 1N5728 thru 1N5757 series of 0.5 watt Zener Voltage Regulators provides a selection from 4.7 to 75 volts in standard 5% tolerances as well as tighter tolerances identified by a “C” or “D” suffix letter on the part number. These glass axial-leaded DO-35 Zeners are also available with an internal-.

1N5750B Datasheet (186.23 KB)
