1N942A-1 Datasheet - Microsemi

1N942A-1 11.7 Volt Temperature Compensated Zener Reference Diodes

The popular 1N941-1 thru 1N945B-1 series of zero-TC reference diodes provides a selection of 11.7 V nominal voltages and temperature coefficients to as low as 0.0002 %/oC for minimal voltage change with temperature when operated at 7.5 mA. The “B” version of these glass, axial-leaded DO-35 reference.

1N942A-1 Features

* JEDEC registered 1N941 thru 1N945 series.

* Standard reference voltage of 11.7 V +/- 5% with tighter reference tolerances of 1%, 2%, and 3% available on

1N942A-1 Datasheet (195.19 KB)

Preview of 1N942A-1 PDF
1N942A-1 Datasheet Preview Page 2 1N942A-1 Datasheet Preview Page 3

Datasheet Details

Part number:

1N942A-1

Manufacturer:

Microsemi ↗

File Size:

195.19 KB

Description:

11.7 volt temperature compensated zener reference diodes.
