SP5748 - 2.4GHz Very Low Phase Noise PLL

Product Overview

Mitel Networks

Datasheet Details

Part number	SP5748
Manufacturer	Mitel Networks
File Size	295.93 KB
Description	2.4GHz Very Low Phase Noise PLL
Datasheet	SP5748 Datasheet
Additional preview pages of the SP5748 datasheet.

Product details

Description

The SP5748 contains all the elements necessary, with the exception of a frequency reference, loop filter and external high voltage transistor, to control a varicap tuned local oscillator, so forming a complete PLL frequency synthesised source.

Features

q Complete 2.4 GHz single chip system (for faster device refer to to SP5768) q Optimised for low phase noise, with comparison frequencies up to 4 MHz q No RF prescaler q Selectable reference division ratio q Reference frequency output q Selectable charge pump current q Integrated loop amplifier q Two switching ports q Low power replacement for SP5658 and 5668 q Downwards software compatible with SP5658 q ESD protection, (Normal ESD handling procedures should be observed) q TV, VCR and Cable tuni.
