A-41661-B10A228

3.96mm (.156) Pitch KK Header

A-41661-B10A228 Datasheet (405.86 KB)

Preview of A-41661-B10A228 PDF Datasheet

Datasheet Details

Part number:

A-41661-B10A228

Manufacturer:

Molex Electronics

File Size:

405.86 KB

Description:

3.96mm (.156) pitch kk header

A-41661-B10A228 General Description

0416610032 Active 3.96mm (.156") Pitch KK® Header, Breakaway, Vertical, 10 Circuits, 0.76µm (30µ") Gold (Au) Selective Plating Documents: 3D Model Drawing (PDF) Product Specification PS-08-50 (PDF) RoHS Certificate of Compliance (PDF) Series LR19980 E29179 image - Reference only EU RoHS China Ro.
