MMA8110EGR2, MMA8225EG, Digital Axis Micromachined Accelerometer

www.DataSheet4U.com Freescale Semiconductor Technical Data Document Number: MMA81XXEG Rev 1, 5/2009 Digital Axis Micromachined Accelerometer The MM.
MMA81XXEG/MMA82XXEG family is a satellite accelerometer which is comprised of a single axis, variable capacitance sensing element with a single channe.

datasheet Preview Page 1 from Datasheet4u.com

MMA8225EG_MotorolaSemiconductorProducts.pdf

MMA8110EGR2 Datasheet Preview — This datasheet PDF includes multiple part numbers: MMA8110EGR2, MMA8225EG. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

MMA8110EGR2, MMA8225EG

Manufacturer:

Motorola Semiconductor Products

File Size:

459.78 KB

Description:

Digital Axis Micromachined Accelerometer

Note:

This datasheet PDF includes multiple part numbers: MMA8110EGR2, MMA8225EG.
Please refer to the document for exact specifications by model.

Features

* Available in 20g, 40g, 50g, 100g, 150g, and 250g (MMA82XXEG, X-axis) and 40g, 100g, 150g, and 250g (MMA81XXEG, Z-axis). Additional g-ranges may be available upon request 80 customer-accessible OTP bits 10-bit digital data output from 8 to 10 bit DSI output 6.3 to 30 V supply voltage On-chi

Applications

* Crash detection (Airbag) Impact and vibration monitoring Shock detection. N/C N/C CREG VPP/TEST CFIL DOUT VGND/DIN CLK 1 2 3 4 5 6 7 8 16 15 14 13 12 11 10 9 VSS VSS BUSRTN BUSIN BUSOUT HCAP VSS CREG 16-PIN SOIC PACKAGE © Freescale Semiconductor, Inc. , 2009. All right
