MMA8125EG, MMA8225EG - Digital Axis Micromachined Accelerometer

Name: MMA8125EG
SKU: MMA8125EG-648746

Motorola Semiconductor Products

📥 Download Datasheet

MMA8125EG Datasheet Preview — This datasheet PDF includes multiple part numbers: MMA8125EG, MMA8225EG. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	MMA8125EG, MMA8225EG
Manufacturer	Motorola Semiconductor Products
File Size	459.78 KB
Description	Digital Axis Micromachined Accelerometer
Datasheet	MMA8225EG_MotorolaSemiconductorProducts.pdf
Note	This datasheet PDF includes multiple part numbers: MMA8125EG, MMA8225EG. Please refer to the document for exact specifications by model.

MMA8125EG Product details

Description

MMA81XXEG/MMA82XXEG family is a satellite accelerometer which is comprised of a single axis, variable capacitance sensing element with a single channel interface IC.

Features

Available in 20g, 40g, 50g, 100g, 150g, and 250g (MMA82XXEG, X-axis) and 40g, 100g, 150g, and 250g (MMA81XXEG, Z-axis). Additional g-ranges may be available upon request 80 customer-accessible OTP bits 10-bit digital data output from 8 to 10 bit DSI output 6.3 to 30 V supply voltage On-chip voltage regulator Internal self-test Minimal external component requirements RoHS compliant (-40 to +125ºC) 16-pin SOIC package Automotive AEC-Q100 qualified DSI 2.0 Compliant Z-axis transducer is o.
