NCR53C96, NCR53C94 Datasheet - NCR Microelectronics

NCR53C96 - Advanced SCSI Controller

The 53C94, 53C95 and 53C96 are high performance CMOS devices conforming to the ANSI standard, X3.l3I-I986, for Small Computer Systems Interface (SCSI).

They are a super-set of the 53C90 with additional commands, registers and an I8-bit DMA interface (two parity bits).

The microprocessor bus width is

NCR53C96 Features

* ANSI X3.13I-I986 compatible

* On-chip 48 rnA drivers

* Control logic for differential tranceivers

* Parity generation, optional checking

* Parity pass-thru

* Software compatible with 53C90

* SCSI-2 tagged -queuing

* I8-bit DMA interfa

NCR53C94-NCRMicroelectronics.pdf

This datasheet PDF includes multiple part numbers: NCR53C96, NCR53C94. Please refer to the document for exact specifications by model.
