NX8561JC - LASER DIODE

Name: NX8561JC
SKU: NX8561JC-475037

NEC

The NX8561JC by NEC is a LASER DIODE. Below is the official datasheet preview.

📥 Download Datasheet

NX8561JC LASER DIODE by NEC - Datasheet Preview — Official preview page of the **NX8561JC** LASER DIODE datasheet (NEC).

Datasheet Details

Part number	NX8561JC
Manufacturer	NEC
File Size	65.72 KB
Description	LASER DIODE
Datasheet	NX8561JC_NEC.pdf
Additional preview pages of the NX8561JC datasheet.

NX8561JC Product details

Description

The NX7660JC is a 1 625 nm newly developed Strained Multiple Quantum Well (St-MQW) structure laser diode DIP module with single mode fiber and internal thermoelectric cooler.

Features

Output power.
Long Wavelength.
Wide operating temperature range Pf = 5 mW MIN. @ IF = 65 mA CW λC = 1 625 nm TC =.
5 to +70 °C.
Internal thermoelectric cooler, thermistor.
Hermetically sealed 14-pin DIP package.
Single mode fiber pigtail.
