BT169DH Datasheet, Scr, NXP

BT169DH Features

• Scr
• Planar passivated for voltage ruggedness and reliability
• Sensitive gate
• Direct triggering from low power gate circuits and logic ICs 3. Applications

PDF File Details

Part number:

BT169DH

Manufacturer:

NXP ↗

File Size:

165.31kb

Download:

📄 Datasheet

Description:

Scr. Planar passivated Silicon Controlled Rectifier with sensitive gate in a SOT54 (TO-92) plastic package. This SCR is designed to be int

BT169DH Application

• Applications
• Ignition circuits
• Lighting ballasts
• Protection circuits
• Switched Mode Power Supplies 4. Quick
