ISP1130DL Universal Serial Bus compound hub with integrated keyboard controller

NXP

Description

ISP1130 Universal Serial Bus compound hub with integrated keyboard controller Rev.01 * 23 March 2000 Objective speciﬁcation 1.General descr.
The ISP1130 integrates a Universal Serial Bus (USB) hub with a keyboard controller into a single chip, which complies with Universal Serial Bus Speciﬁ.

📥 Download Datasheet

ISP1130DL Datasheet Preview — Preview of ISP1130DL PDF

Datasheet Specifications

Part number: ISP1130DL
Manufacturer: NXP ↗
File Size: 1.74 MB
Datasheet: ISP1130DL_PhilipsSemiconductors.pdf
Description: Universal Serial Bus compound hub with integrated keyboard controller

Features

* allow signiﬁcant cost savings in system design and easy implementation of advanced USB functionality into PC peripherals. 2. Features s Compound USB hub device with integrated hub repeater, hub controller, Serial Interface Engine (SIE), data transceivers and 5 V to 3.3 V voltage regulator s Complie

Applications

* Integrated 80C51 microcontroller core with 8 kbytes mask ROM and 256 bytes data RAM On-chip watchdog timer for automatic fault recovery Internal power-on reset and low-voltage reset circuit Individual power switching for downstream ports Individual port overcurrent protection with built-in sense cir
