ISP1505A Datasheet, Transceiver, NXP

ISP1505A Features

• Transceiver I Fully complies with: N Universal Serial Bus Specification Rev. 2.0 N UTMI+ Low Pin Interface (ULPI) Specification Rev. 1.1 I Interfaces to host and peripheral cores; optimized for stand

PDF File Details

Part number:

ISP1505A

Manufacturer:

NXP ↗

File Size:

0.98MB

Download:

📄 Datasheet

Description:

Ulpi hi speed usb transceiver. The ISP1505 is a Universal Serial Bus (USB) high-speed host and peripheral transceiver that is fully compliant with Universal Serial

ISP1505A Application

• Applications with an external VBUS supply; stand-alone peripheral cores, and Session Request Protocol (SRP)-capable peripheral cores I Complete Hi-S
