LFE15600X Datasheet, Transistor, NXP

LFE15600X Features

• Transistor
• Diffused emitter ballasting resistors providing excellent current sharing and withstanding a high VSWR
• Interdigitated structure provides high emitter efficiency

PDF File Details

Part number:

LFE15600X

Manufacturer:

NXP ↗

File Size:

72.49kb

Download:

📄 Datasheet

Description:

Npn microwave power transistor. NPN silicon planar epitaxial microwave power transistor in a SOT448A glued cap metal ceramic flange package, with emitter connected t

LFE15600X Application

• Applications Common emitter, class AB amplifiers in CW conditions for professional applications between 1.5 GHz and 1.7 GHz. DESCRIPTION NPN silicon
