NT5CB64M16DP, NT5CB128M8DN - 1Gb DDR3 SDRAM

Nanya

Datasheet Details

Part number	NT5CB64M16DP, NT5CB128M8DN
Manufacturer	Nanya
File Size	2.62 MB
Description	1Gb DDR3 SDRAM
Datasheet	NT5CB128M8DN-Nanya.pdf
Note	This datasheet PDF includes multiple part numbers: NT5CB64M16DP, NT5CB128M8DN. Please refer to the document for exact specifications by model.

The 1Gb Double-Data-Rate-3 (DDR3/L) B-die DRAMs is double data rate architecture to achieve high-speed operation.

and all of the control and address inputs are synchronized with a pair of externally supplied differential clocks. Inputs are latched at the cross point of differential clocks (CK rising and falling). All I/Os are synchronized with a single ended DQS or differential DQS pair in a source synchronous fashion. These devices operate with a single 1.5V ± 0.075V or 1.35V -0.067/+0.1V power supply and are available in BGA packages. DCC Version 1.1 01 / 2014 3 © NANYA.
