54AC541 Datasheet, Driver, National Semiconductor

54AC541 Features

• Driver n ICC and IOZ reduced by 50% n TRI-STATE outputs n Inputs and outputs opposite side of package, allowing easier interface to microprocessors n Output source/sink 24 mA n ’AC540 provides

PDF File Details

Part number:

54AC541

Manufacturer:

National Semiconductor

File Size:

149.03kb

Download:

📄 Datasheet

Description:

Octal buffer/line driver. The ’AC541 is an octal buffer/line driver designed to be employed as memory and address drivers, clock drivers and bus oriented trans
