54LVXC4245 Datasheet, Transceiver, National Semiconductor

54LVXC4245 Features

• Transceiver Bidirectional interface between 5V and 3V-to-5V buses Control inputs compatible with TTL level Outputs source/sink up to 24 mA Available in Cerpack and CDIP packages Implements patented

PDF File Details

Part number:

54LVXC4245

Manufacturer:

National Semiconductor

File Size:

134.28kb

Download:

📄 Datasheet

Description:

8-bit dual supply configurable voltage interface transceiver. The LVXC4245 is a 24-pin dual-supply, 8-bit configurable voltage interface transceiver suited for real time configurable I/O applicat

54LVXC4245 Application

• Applications The VCCA pin accepts a 5V supply level. The “A” port is a dedicated 5V port. The VCCB pin accepts a 3V-to-5V supply level. The “B” por
