CGS3311 - CMOS Crystal Clock Generators

National Semiconductor

CGS3311 Datasheet Preview — Preview of CGS3311 PDF

Datasheet Details

Part number	CGS3311
Manufacturer	National Semiconductor ↗
File Size	214.35 KB
Description	CMOS Crystal Clock Generators
Datasheet	CGS3311-NationalSemiconductor.pdf

CGS3311 Product details

Description

These devices are designed for Clock Generation and Sup- CD port (CGSTM) applications up to 110 MHz.The CGS331 x C") series of devices are crystal controlled CMOS oscillators enC") requiring a minimum of external components.The 331 x de- oC!J vices provide selectable output divide ratio (and selectable crystal drive level).The circuit is designed to operate over a LI) wide frequency range using fundamental model or overtone C") crystals. Crystal frequency operation range: fund

Features

National's CGSTM family of devices for high frequency.
Output has high speed short circuit protection.
Basic oscillator type: Pierce.
Hysteresis inputs to improve noise margin . ~ clock source.
