DAC0831 Datasheet - National Semiconductor

8-Bit P Compatible/ Double-Buffered D/A Converters

DAC0831 Features

* n Double-buffered, single-buffered or flow-through digital data inputs n Easy interchange and pin-compatible with 12-bit DAC1230 series n Direct interface to all popular microprocessors n Linearity specified with zero and full scale adjust only

* NOT BEST STRAIGHT LINE FIT. n Works with ± 10

DAC0831 General Description

The DAC0830 is an advanced CMOS/Si-Cr 8-bit multiplying DAC designed to interface directly with the 8080, 8048, 8085, Z80 ® , and other popular microprocessors. A deposited silicon-chromium R-2R resistor ladder network divides the reference current and provides the circuit with excellent temperature.

DAC0831 Datasheet (532.18 KB)

DAC0831 Datasheet Preview — Preview of DAC0831 PDF

Datasheet Details

Part number:

DAC0831

Manufacturer:

National Semiconductor

File Size:

532.18 KB

Description:

8-bit p compatible/ double-buffered d/a converters.
DAC0830/DAC0832 8-Bit µP Compatible, Double-Buffered D to A Converters May 1999 DAC0830/DAC0832 8-Bit µP Compatible, Double-Buffered D to A Converte.
