DP84240 - (DP84240 / DP84244) TRI-STATE Drivers Which are Designed For Heavy Capacitive Load Applications

Download the DP84240 datasheet PDF. This datasheet also covers the DP84244 variant, as both devices belong to the same (dp84240 / dp84244) tri-state drivers which are designed for heavy capacitive load applications family and are provided as variant models within a single manufacturer datasheet.

Description

The DP84240 and DP84244 are octal TRI-STATE drivers which are designed for heavy capacitive load applications such as fast data buffers or as memory address drivers The DP84240 is an inverting driver which is pin-compatible with both the 74S240 and AM2965 The DP84244 is a non-inverting driver which

Features

  • Y Y Y Y Y Y Y Y tpd specified with 250 pF and 500 pF loads Output specified from 0 8V to 2 7V Designed for symmetric rise and fall times at 500 pF Outputs glitch free at power up and power down PNP inputs reduce DC loading on bus lines Low static and dynamic input capacitance Low skew times between edges and pins AC parameters specified with all outputs switching simultaneously Connection Diagram Truth Table DP84240 Inputs G H L L H e High Level L e Low Level X e Don’t Care Z e High Impedance.
