LM108AJAN - Operational Amplifiers

Description

The LM108 is a precision operational amplifier having specifications a factor of ten better than FET amplifiers over a

55° C to +125°C temperature range.

The devices operate with supply voltages from ±2V to ±20V and have sufficient supply rejection to use unregulated supplies.

Features

  • Maximum input bias current of 3.0 nA over temperature.
  • Offset current less than 400 pA over temperature.
  • Supply current of only 300 μA, even in saturation.
  • Guaranteed drift characteristics Ordering Information NS PART NUMBER JL108ABGA JL108ABPA JL108ABCA JL108ABHA JL108ABZA JL108ASGA JL108ASPA JL108ASCA JL108ASHA SMD PART NUMBER JM38510/10104BGA JM38510/10104BPA JM38510/10104BCA JM38510/10104BHA JM38510/10104BZA JM38510/10104SGA JM38510/10104SPA JM38510/10104SCA JM38510/1.

📥 Download Datasheet

Datasheet preview – LM108AJAN

📁 Similar Datasheet

  • LM108AJAN - Operational Amplifiers (Texas Instruments)
  • LM108A - Precision Single OPAMP (Tomson)
  • LM108A - Operational Amplifiersbb (Linear Technology)
  • LM108A - Precision Operational Amplifiers (Fairchild)
  • LM108AQML - Operational Amplifiers (Texas Instruments)
  • LM108 - Precision Single OPAMP (Tomson)
  • LM108 - Operational Amplifier (Linear Technology)
  • LM108-N - Operational Amplifiers (Texas Instruments)
  • LM1084 - 5-A Low Dropout Positive Regulators (Texas Instruments)
  • LM1084 - 5.0A LDO Voltage Regulator (HTC)
Other Datasheets by National Semiconductor
  • LM108A - Operational Amplifiers
  • LM108 - Operational Amplifiers
  • LM1084 - 5A Low Dropout Positive Regulators
  • LM1085 - 3A Low Dropout Positive Regulators
  • LM1086 - 1.5A Low Dropout Positive Regulators
  • LM10 - Operational Amplifier/Voltage
  • LM100 - Voltage Regulator
  • LM1017 - 4-Bit Binary 7-Segment Decoder/Driver

Full PDF Text Transcription

Click to expand full text
LM108AJAN Operational Amplifiers LM108AJAN OBSOLETE September 29, 2010 Operational Amplifiers General Description The LM108 is a precision operational amplifier having specifications a factor of ten better than FET amplifiers over a −55° C to +125°C temperature range. The devices operate with supply voltages from ±2V to ±20V and have sufficient supply rejection to use unregulated supplies. Although the circuit is interchangeable with, and uses the same compensation as the LM101A, an alternate compensation scheme can be used to make it particularly insensitive to power supply noise and to make supply bypass capacitors unnecessary. The low current error of the LM108 makes possible many designs that are not practical with conventional amplifiers.
