8M05D

500mA Positive Voltage Regulator

8M05D Features

* No External Components Required

* Internal Thermal Overload Protection

* Internal Short Circuit Current Limiting

* Output Transistor Safe

* Area Compensation

* MC78M00A High Accuracy (±2%) Available for 5.0 V, 8.0 V, 12 V and 15 V

* NCV Prefix

8M05D General Description

The MC78M00/MC78M00A Series positive voltage regulators are identical to the popular MC7800 Series devices, except that they are specified for only half the output current. Like the MC7800 devices, the MC78M00 three

*terminal regulators are intended for local, on

*card voltage regulati.

8M05D Datasheet (307.05 KB)

Preview of 8M05D PDF

Datasheet Details

Part number:

8M05D

Manufacturer:

ON Semiconductor ↗

File Size:

307.05 KB

Description:

500ma positive voltage regulator.
