LC72121MA - PLL Frequency Synthesizers

Datasheet Summary

Features

  • High-speed programmable divider.
  • FMIN: 10 to 160MHz.
  • Pulse swallower technique (With built-in divide-by-2 prescaler).
  • AMIN: 2 to 40MHz.
  • Pulse swallower technique 0.5 to 10MHz.
  • Direct division technique.
  • IF counter.
  • IFIN: 0.4 to.
