MC14001UB UB-Suffix Series CMOS Gates

MC14001UB Description

MC14001UB, MC14011UB UB-Suffix Series CMOS Gates The UB Series logic gates are constructed with P and N channel enhancement mode devices in a single .

MC14001UB Features

* Supply Voltage Range = 3.0 Vdc to 18 Vdc

MC14001UB Applications

* Capable of Driving Two Low
* Power TTL Loads or One Low
* Power Schottky TTL Load Over the Rated Temperature Range
* Double Diode Protection on All Inputs
* Pin
* for
* Pin Replacements for Corresponding CD4000 Series UB Suffix Devices
