MC74HC4016 Quad Analog Switch / Multiplexer / Demultiplexer

MC74HC4016 Quad Analog Switch/ Multiplexer/Demultiplexer High Performance Silicon Gate CMOS The MC54/74HC4016 utilizes silicon gate CMOS technology to achieve fast propagation delays, low ON resistances, and low OFF channel leakage current. This bilateral switch/multiplexer/demultiplexer controls analog and digital voltages that may vary across the full power supply range (from VCC to GND). The HC4016 is identical in pinout to the metal gate CMOS.

MC74HC4016_ONSemiconductor.pdf

Preview of MC74HC4016 PDF
MC74HC4016 Datasheet Preview Page 2 MC74HC4016 Datasheet Preview Page 3

Datasheet Details

Part number:

MC74HC4016

Manufacturer:

ON Semiconductor ↗

File Size:

281.95 KB

Description:

Quad analog switch / multiplexer / demultiplexer.
