MC74VHC1G32 - 2-Input OR Gate

ON Semiconductor

The MC74VHC1G32 by ON Semiconductor is a 2-Input OR Gate. Below is the official datasheet preview.

📥 Download Datasheet

MC74VHC1G32 2-Input OR Gate by ON Semiconductor - Datasheet Preview — Official preview page of the MC74VHC1G32 2-Input OR Gate datasheet (ON Semiconductor).

Datasheet Details

Part number	MC74VHC1G32
Manufacturer	ON Semiconductor
File Size	540.10 KB
Description	2-Input OR Gate
Datasheet	MC74VHC1G32_ONSemiconductor.pdf
Additional preview pages of the MC74VHC1G32 datasheet.

MC74VHC1G32 Product details

Features

Designed for 2.0 V to 5.5 V VCC Operation.
3.7 ns tPD at 5 V (typ).
Inputs/Outputs Over.
Voltage Tolerant up to 5.5 V.
IOFF Supports Partial Power Down Protection.
Source/Sink 8 mA at 3.0 V.
Available in SC.
88A, SC.
74A, SOT.
953 and UDFN6 Packages.
Chip Complexity < 100 FETs.
Q Suffix for Automotive and Other.
