MMBD1010LT1 - Switching Diode

MMBD1010LT1 Description

MMBD1010LT1 Switching Diode Part of the GreenLine™ Portfolio of devices with energy *conserving traits.This switching diode has the following .

MMBD1010LT1 Features

* Very Low Leakage (≤ 500 pA) promotes extended battery life by decreasing energy waste. Guaranteed leakage limit is for each diode in the pair contingent upon the other diode being in a non
* forward
* biased condition.
* Offered in four Surface Mount package types

MMBD1010LT1 Applications

* ESD Protection
* Reverse Polarity Protection
* Steering Logic
* Medium
* Speed Switching MAXIMUM RATINGS Rating Symbol Value Unit Continuous Reverse Voltage Peak Forward Current Peak Forward Surge Current DEVICE MARKING VR 30 Vdc IF 200 mAdc IFM (surg

📥 Download Datasheet

Preview of MMBD1010LT1 PDF
datasheet Preview Page 2 datasheet Preview Page 3
