MUR10120E Datasheet - ON Semiconductor

MUR10120E Power Rectifier

MUR10120E Preferred Device SCANSWITCH™ Power Rectifier For High and Very High Resolution Monitors This state of the art power rectifier is specifically designed for use as a damper diode in horizontal deflection circuits for high and very high resolution monitors. 1200 Volt Blocking Voltage 20 mJ Avalanche Energy (Guaranteed) 12 Volt (Typical) Peak Transient Overshoot Voltage 135 ns (Typical) Forward Recovery Time Mechanical Charac.

MUR10120E Datasheet (121.14 KB)

Preview of MUR10120E PDF
MUR10120E Datasheet Preview Page 2 MUR10120E Datasheet Preview Page 3

Datasheet Details

Part number:

MUR10120E

Manufacturer:

ON Semiconductor ↗

File Size:

121.14 KB

Description:

Power rectifier.
