NLSV1T34 - 1-Bit Dual-Supply Non-Inverting Level Translator

ON Semiconductor

📥 Download Datasheet

NLSV1T34 Datasheet Preview — Preview of NLSV1T34 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	NLSV1T34
Manufacturer	ON Semiconductor ↗
File Size	278.17 KB
Description	1-Bit Dual-Supply Non-Inverting Level Translator
Datasheet	NLSV1T34-ONSemiconductor.pdf

NLSV1T34 Product details

Features

Wide VCCA and VCCB Operating Range: 0.9 V to 4.5 V.
High.
Speed w/ Balanced Propagation Delay.
Inputs and Outputs have OVT Protection to 4.5 V.
Non.
preferential VCCA and VCCB Sequencing.
Power.
Off Protection.
Power.
Off High Impedance Inputs and Outputs.
Ultra.
Small Packaging: 1.45 mm x 1.0 mm ULLGA6 2.0 mm x 2.1 mm SC.
88A 1.2 mm x 1.0 mm UDFN6 1.45 mm x 1.0 mm UDFN6.
NLV Prefix.
