* Provides a Robust Driver Interface Between D.C. Relay Coil and Sensitive Logic Circuits
* Optimized to Switch Relays of 12 V Rail
* Capable of Driving Relay Coils Rated up to 6.0 W at 12 V
* Internal Zener Eliminates the Need of Free
* Wheeling Diode
NUD3112
233.32 KB
Inductive load driver.
DATA SHEET www.onsemi.com
Integrated Relay, Inductive Load Driver
NUD3112
This device is used to switch inductive loads such as relays, solenoids inc.
