P6KE6.8CA 600 Watt Peak Power Surmetic 40 Zener Transient Voltage Suppressors

600 Watt Peak Power Surmetic 40 Zener Transient Voltage Suppressors P6KE6.8CA Series Bidirectional The P6KE6.8CA series is designed to protect voltage sensitive components from high voltage, high energy transients. They have excellent clamping capability, high surge capability, low zener impedance and fast response time. These devices are ON Semiconductor’s exclusive, cost-effective, highly reliable Surmetic axial leaded package and is ideally-suited for use in communication systems, numer.

P6KE6.8CA Features

* Working Peak Reverse Voltage Range

* 5.8 to 171 V

* Peak Power

* 600 Watts @ 1 ms

* ESD Rating of class 3 (>16 KV) per Human Body Model

* Maximum Clamp Voltage @ Peak Pulse Current

* Low Leakage < 5 mA above 10 V

* Maximum Temperatur
