OV9713 - CMOS WXGA (1 megapixel) HD sensor

OmniVision

📥 Download Datasheet

OV9713 Datasheet Preview — Preview of OV9713 PDF

Datasheet Details

Part number: OV9713
Manufacturer: OmniVision
File Size: 1.06 MB
Datasheet: OV9713-OmniVision.pdf
Description: CMOS WXGA (1 megapixel) HD sensor

OV9713 Product details

Description

2 system level description 2.1 overview 2.2 architecture 2.3 format and frame 2.4 I/O control 2.5 MIPI interface 2.6 VSYNC timing in MIPI mode 2.6.1 VSYNC modes 2.7 power management 2.7.1 power up sequence 2.7.2 power down sequence 2.8 reset 2.8.1 power ON reset generation 2.9 hardware and software standby 2.10 system clock control 2.10.1 PLL configuration 2.11 serial camera control bus (SCCB) interface 2.11.1 data transfer protocol 2.11.2 message format 2.11.3 read / write operation 2.11.4 SCC

Features

automatic black level calibration (ABLC) programmable controls for frame rate, mirror and flip, cropping and windowing image quality controls: lens correction and defective pixel canceling supports output formats: 8/10/12-bit RAW RGB (MIPI/LVDS) supports horizontal and vertical sub-sampling supports images sizes: 1280x800, 640x400, and 320x200 fast mode switching 00key specifications (typical) active array size: 1296 x 812 power supply: core: 1.5VDC ± 5% analog: 2.6 ~ 3.0V I/O:.
