GS1D-L, GS1A-L - RECTIFIER

PAN JIT

GS1D-L Description

GS1A-L~GS1M-L GLASS PASSIVATED RECTIFIER VOLTAGE 50 to 1000 Volt CURRENT 1 Ampere .

GS1D-L Applications

* in order to optimize board space
* Easy pick and place
* Plastic package has Underwriters Laboratory Flammability Classification 94V-O
* Low Forward Drop
* High temperature soldering : 260°C /10 seconds at terminals
* Glass Passivated Junction MECHANICAL DATA

📥 Download Datasheet

GS1D-L Datasheet Preview — This datasheet PDF includes multiple part numbers: GS1D-L, GS1A-L. Please refer to the document for exact specifications by model.

Datasheet Details

Part number: GS1D-L, GS1A-L
Manufacturer: PAN JIT
File Size: 1.64 MB
Datasheet: GS1A-L-PANJIT.pdf
Description: RECTIFIER
Note: This datasheet PDF includes multiple part numbers: GS1D-L, GS1A-L.
Please refer to the document for exact specifications by model.
