PT12916 Datasheet - PTC

3 Band EQ Car Audio Processor

PT12916 Features

* Controlled by I²C Bus Micro-Processor Interface

* Input Gain from 0 to +15dB with 1dB/step BLOCK DIAGRAM

* 8 stereo Inputs for audio sources

* 1 Quasi-Differential input for external auxiliary input.

* 1 Fully-Differential input for auxiliary input or disc changer.

* 2 mon

PT12916 General Description

The PT12916 is a car audio processor with 10 input sources selector and 3-band equalizer, which includes a fully integrated high performance audio filters that are built into a single chip to provide audio system having the highest audio performance and reliability. Digital control allows programmin.

PT12916 Datasheet (92.84 KB)

PT12916 Datasheet Preview — Preview of PT12916 PDF

Datasheet Details

Part number:

PT12916

Manufacturer:

PTC

File Size:

92.84 KB

Description:

3 band eq car audio processor.
