Part number: SB4040PT
Manufacturer: Pan Jit International
File Size: 181.72KB
Download: 📄 Datasheet
Description: (SB4020PT - SB4060PT) Isolation Schottky Barrier Rectifiers
* Plastic package has Underwriters Laboratory Flammability Classification 94V-O. Flame Retardant Epoxy Molding Compound.
* Exceeds environmental standards of MIL-.
* Both normal and Pb free product are available : Normal : 80~95% Sn, 5~20% Pb Pb free: 99% Sn above can meet Rohs .
Image gallery
