Power Transistors
2SB0928 (2SB928), 2SB0928A (2SB928A)
www.DataSheet4U.net
Silicon PNP epitaxial planar type
For Power amplification For TV vertical deflection output Complementary to 2SD1250 and 2SD1250A ■ Features
• High collector-emitter voltage (Base open) VCEO • High collector power dissipation PC • N type package enabling direct soldering of the radiating fin to the printed circuit board, etc. of small electronic equipment.
Unit : mm
8.5±0.2 6.0±0.2 3.4±0.3 1.0±0.1
10.0±0.3 1.5±0.1
4.4±0.5
■ Absolute Maximum Ratings TC = 25°C
Parameter Collector-base voltage (Emitter open) Collector-emitter voltage 2SB0928 (Base open) 2SB0928A VEBO IC ICP PC Ta = 25°C Tj Tstg Symbol VCBO VCEO Rating −200 −150 −180 −6 −2 −3 30 1.3 150 −55 ∼ +150 °C °C V A A W Unit V V
(6.
