MA6D52 Fast Recovery Diode

Panasonic

Description

Fast Recovery Diodes (FRD) MA3D652 (MA6D52) Silicon planar type (cathode common) For high-frequency rectification 9.9±0.3 Unit: mm 4.6±0.2 2.9±0.2.

📥 Download Datasheet

MA6D52 Datasheet Preview — Preview of MA6D52 PDF

Datasheet Specifications

Part number: MA6D52
Manufacturer: Panasonic
File Size: 217.77 KB
Datasheet: MA6D52-Panasonic.pdf
Description: Fast Recovery Diode

Features

* φ 3.2±0.1 15.0±0.5
* Low forward voltage VF
* Fast reverse recovery time trr
* TO-220D (Full-pack package) with high dielectric breakdown voltage
* Easy-to-mount, caused by its V cut lead end 1.4±0.2 1.6±0.2 2.6±0.1 /
* Absolute Maximum Ratings Ta = 25°C

Applications

* or general electronic equipment (such as office equipment, communications equipment, measuring instruments and household appliances). Consult our sales staff in advance for information on the following applications:
* Special applications (such as for airplanes, aerospace, automobiles, traff
