MA81200M, MA8 - Silicon planar type

Name: MA81200M
SKU: MA81200M-403084

Panasonic

The MA81200M by Panasonic is a Silicon planar type. Below is the official datasheet preview.

Datasheet Details

Part number	MA81200M, MA8
Manufacturer	Panasonic
File Size	69.49 KB
Description	Silicon planar type
Datasheet	MA8-024.pdf
Note	This datasheet PDF includes multiple part numbers: MA81200M, MA8. Please refer to the document for exact specifications by model.
Additional preview pages of the MA81200M datasheet.

Extremely low noise voltage caused from the diode (2.4V to 39V, 1/3 to 1/10 of our conventional MAZ3000 series).
Extremely good rising performance (in the low-current range).
Easy-to-select the optimum diode because of their finely divided zener-voltage ranks.
Guaranteed reliability, equivalent to that of conventional products (Mini type package).
Allowing to reduce the mounting area, thickness and weight substantially, compared with those of the con.
