74HC238 Datasheet, Decoder/demultiplexer, Philips

74HC238 Features

• Decoder/demultiplexer
• Demultiplexing capability
• Multiple input enable for easy expansion
• Ideal for memory chip select decoding
• Active HIGH mutually exclusive outputs <

PDF File Details

Part number:

74HC238

Manufacturer:

Philips

File Size:

49.61kb

Download:

📄 Datasheet

Description:

3-to-8 line decoder/demultiplexer. The 74HC/HCT238 are high-speed Si-gate CMOS devices and are pin compatible with low power Schottky TTL (LSTTL). They are specified in
